Projects

Handpicked case studies spanning new builds, conversions, piping & machinery, and engineering analyses.

15.6 m Aluminium Crew Boat (BV)
New Build18 knotsAluminiumBV

15.6 m Aluminium Crew Boat (BV)

  • High-speed hull optimized for lightweight strength and fuel efficiency.
  • Stability for 20 pax + 4 crew and 30T deck load (1T/m²).
  • Twin 380 HP, 600 mm props, ISO 11591 visibility; scantlings per BV NR600/NI 517.
Ask about a similar projectFrom our project deck
100 ft Luxury Yacht – Basic Design
New BuildYachtBV

100 ft Luxury Yacht – Basic Design

  • Hydrodynamic hull + superstructure with premium accommodation.
  • Intact & damage stability (BV); HVAC/bilge/fuel/fire systems integrated.
  • Jacuzzi, sun deck, side balconies engineered without compromising structure.
Ask about a similar projectFrom our project deck
ASM 52C – 52 ft Passenger Boat
New Build20 knotsGCC Code

ASM 52C – 52 ft Passenger Boat

  • Twin Volvo Penta D6-440 (2×440 HP); 42-pax seating GA and escapes.
  • Hull framing, engine foundations per GCC Code; lines/midship/systems submitted.
  • Hydrostatics + stability for full/partial load; design approved by authority.
Ask about a similar projectFrom our project deck
Al Qais – 15.47 m Pleasure Fishing Boat
New BuildOutboards15 kn

Al Qais – 15.47 m Pleasure Fishing Boat

  • 3 outboards; layout for 8 pax + 2 crew with open fishing deck.
  • GA, engine mounting, and structural framing; shallow-draft, efficient hull.
  • Drawings & tech docs for local approval.
Ask about a similar projectFrom our project deck
ROYAL-1 Multistory Houseboat (19.2 × 8 m)
New BuildTwin OB12 kn

ROYAL-1 Multistory Houseboat (19.2 × 8 m)

  • GA across decks (lounge, cabins, kitchen, upper viewing).
  • Structural design for wide beam + superstructure loads; comfort & stability.
  • Fabrication package prepared for authority approval.
Ask about a similar projectFrom our project deck
35 m Passenger Catamaran – Stability & Class (PRS)
New BuildCatamaranPRS

35 m Passenger Catamaran – Stability & Class (PRS)

  • Intact & damage stability for multiple load cases.
  • GA, tank, bulkhead, WT integrity, escape route drawings.
  • Compliance and approval from PRS for passenger craft.
Ask about a similar projectFrom our project deck
26 m Passenger → Crew Supply Conversion
ConversionConversionClassed

26 m Passenger → Crew Supply Conversion

  • Converted non-class passenger vessel to classed crew boat.
  • Profile & GA modifications; systems and class documentation.
Ask about a similar projectFrom our project deck
FPSO Conversion – Structural & Piping Packages
ConversionFPSOFatigueVibration

FPSO Conversion – Structural & Piping Packages

  • Pipe stress analysis + isometrics; steam/UPS spaces layouts.
  • Funnel structural design; crane foundation fatigue assessment.
  • Structural vibration study for machinery spaces.
Ask about a similar projectFrom our project deck
Oil → Bitumen Carrier Conversion
ConversionThermalHeating CoilsInsulation

Oil → Bitumen Carrier Conversion

  • Thermal-oil boilers; in-tank heating coils for uniform temperature.
  • Thermal insulation for tanks & lines to minimize heat loss.
Ask about a similar projectFrom our project deck
33 m Houseboat – Hull & Structural Modification (Tasneef)
RetrofitFRP hullsGlobal StrengthLifting

33 m Houseboat – Hull & Structural Modification (Tasneef)

  • Removed 6 pipe hulls; designed 3 new FRP hulls for weight reduction.
  • Global strength verification; lifting analysis for section handling.
  • Full stability calculations and Tasneef compliance.
Ask about a similar projectFrom our project deck
WWE-214 Accommodation Barge (BV – SPS Code)
ConversionIncliningDamage StabilityDeck Reinforcement

WWE-214 Accommodation Barge (BV – SPS Code)

  • New accommodation block; inclining + intact/damage stability per SPS.
  • FEA of block structure; deck strengthening for excavator loads.
  • BV approval under SPS compliance.
Ask about a similar projectFrom our project deck
Mooring & Sea Fastening
AnalysisBargeCraneMooring

Mooring & Sea Fastening

  • Crane sea-fastening design on barge, including grillage and tie-downs.
  • Mooring layouts and analyses for excavation barges.
Ask about a similar projectFrom our project deck
Scrubber Retrofit – Detail Room & Piping
RetrofitSOx3D Scan

Scrubber Retrofit – Detail Room & Piping

  • 3D scan-based room geometry; detailed equipment integration.
  • Piping routing, supports, and interfaces to ship systems.
Ask about a similar projectFrom our project deck
Pipe Stress Analysis – Steam / GRE / Jacketed Systems
Piping & MachineryStressSupports

Pipe Stress Analysis – Steam / GRE / Jacketed Systems

  • Code-based stress checks with anchor/guide/spring support selection.
  • Operating, thermal, and occasional load cases evaluated.
Ask about a similar projectFrom our project deck
Water Hammer Analysis
Piping & MachineryTransientImpulse

Water Hammer Analysis

  • Transient surge modelling (Impulse) with valve/pump trip scenarios.
  • Mitigation devices sized and located for safe operation.
Ask about a similar projectFrom our project deck
Flow Analysis – Helideck Sprinkler & Pressure Drop
Piping & MachineryHydraulicsSprinkler

Flow Analysis – Helideck Sprinkler & Pressure Drop

  • Network models for helideck sprinklers; coverage & pressure checks.
  • System pressure-drop assessment across operating ranges.
Ask about a similar projectFrom our project deck
